Re350lrf Laser Ranging Binocular Infrared Thermal Imaging

Onick RE350LRF laser ranging binocular handheld thermal imager is an instrument equipped with a new type of high-sensitivity uncooled infrared focal plane detector, advanced imaging circuit, and optimized optical system. The product appearance and structural design conforms to the ergonomic optimization design.
€0
Product Details
Product Details

Onick RE350LRF laser ranging binocular handheld thermal imager is an instrument equipped with a new type of high-sensitivity uncooled infrared focal plane detector, advanced imaging circuit, and optimized optical system. The product appearance and structural design conforms to the ergonomic optimization design.

The Onick RE350LRF laser ranging binocular handheld thermal imager has a built-in laser ranging module and supports laser ranging. Good infrared imaging effect, small and light size, low power consumption, simple operation, light and portable appearance structure and good grip feel. The product is equipped with a high-quality rubber soft cover, which is optimized according to the human hand shape, so that users have a good single-handed and double-handed grip experience. The product has enhanced waterproof design and reaches the IP67 protection level.

The Onick RE350LRF can be used for handheld or fixed observation, night reconnaissance, evidence collection and target search, and has photo/video evidence collection functions, which can record video images for a long time. The product uses a single built-in rechargeable battery and can work continuously for up to 8 hours. Onick RE350LRF has GPS Beidou positioning, electronic compass function, and WIFI transmission function.

Product features:

1. Supports photo and video evidence collection functions, and can record video images for a long time;

2. Built-in laser ranging module, supports 2000m laser ranging, with high ranging accuracy;

3. With GPS Beidou positioning, electronic compass function, WIFI transmission function;

4. Long standby time, built-in rechargeable battery, continuous working time can reach 8 hours;

5. Small and light, low power consumption, simple operation, light and portable appearance structure, ergonomic structure;

6. Fast start-up, simple operation, compact and stable structure, protection level IP67;

Approved for China's recognition and international mutual recognition inspection report: Inspection report of the Quality Inspection Center of Security and Police Electronic Products of the Ministry of Public Security, Gongjingjian No. 2306110045.

Application areas:

Can record and take pictures, can record and restore the scene, can be used in patrol, law enforcement, search and rescue, drug and smuggling, prisoner pursuit and other scenes. It is suitable for special forces such as public security, armed police, and the military to achieve effective all-weather observation of specific areas or targets, and quickly discover, identify, and track targets of concern; it is also suitable for industries such as fire protection, electricity, and petroleum to achieve day and night monitoring of specific areas or equipment.

Product Model
Onick RE350LRF

Type
Uncooled VOX

Wave Type
8-14μm

Pikel Size
12μm
Detector performance
Resolution
384*288

Frame Rate
50Hz

NETD
≤50mK

Objective focal distance
50mm

Magnification
4.8x
Optical Parameter
Field Angel
5.3°x3.9°

Minimum imaging distance
5m

Diopter Regulation
-5D-5D

Display Mode
Binocular Imaging

Display Type
OLED
Display
Display Resolution
1024*768

Electronic Magnification
1x/2x/4x

Color Palette
Black Hot/White Hot/Green Hot/Fusion

Start-up Time
≤5 seconds

Image Enhancement
DDE

Brightness and contrast
AGC
Function
WIFI
WIFI Video Output

4G Image Transmission
Data image wireless transmission(Optional)

Take photo/video
32G storage

Online Update
Code and graphical user interface resources
International
Protection Class
IP67
Adaptation
Operation Temperature
-40ºC-50ºC

Storage Temperature
-40ºC-60ºC
Physical Characteristics
Net Weight
1150g
Product Size
204*154*73mm
View Distance
Operation Distance
≥4000m (1.8*0.5m)

≥1500m(1.8*0.5)
Power Supply
Battery Type
Build-in Lithium Battery
Recharge
5V TYPEC USB
Operation Time
8 Hours(Without WIFI)

Laser Safty Grade
Class 1
Laser Range
Measurement Range
5-2000m

Measurement Accuracy
±0.3m

Pitch Angel
+/-0-90° or +/-0-180°

Roll Angel
+/-0-90°
Electronic Compass
Resolution
0.1°

Accuracy Rate
2%

Low Power Consumption
3.3V-5V 18mA

Positioning System
BDS/GPS/QZSS/GLONASS
GPS/BDS
Position Accuracy
2.5m(CEP50)

Sensitivity
-162dBm
